EPS Lunch Box Or Foam Plate Making Machine Forming Speed 15-20 Cycles / Min

EPS Lunch Box Or Foam Plate Making Machine Forming Speed 15-20 Cycles / Min
EPS Lunch Box Or Foam Plate Making Machine Forming Speed 15-20 Cycles / Min EPS Lunch Box Or Foam Plate Making Machine Forming Speed 15-20 Cycles / Min EPS Lunch Box Or Foam Plate Making Machine Forming Speed 15-20 Cycles / Min EPS Lunch Box Or Foam Plate Making Machine Forming Speed 15-20 Cycles / Min

Large Image :  EPS Lunch Box Or Foam Plate Making Machine Forming Speed 15-20 Cycles / Min

Product Details:

Place of Origin: CHINA
Brand Name: HONGRUN
Certification: ISO9001, CE, SGS, BV, TUV
Model Number: HR-S1080

Payment & Shipping Terms:

Minimum Order Quantity: 1SET
Price: negotiation
Packaging Details: Standard Export Packaging
Delivery Time: 90days
Payment Terms: T/T, L/C
Supply Ability: 100SETS PER YEAR
Detailed Product Description
Product Type: Fast Food Box Weight: 16 Ton
Voltage: 380v Disposable Foam Plates Making Machine Warranty: One Year
Processing Type: Foaming Machine Automatic: Fully Automatic
Product Name: PS Foam Food Box Machine,PS Foam Plate Making Machine Forming Area: 750*1000mm
Forming Speed: 15-20 Cycles/min Max. Depth: 80mm
High Light:

thermocol plate making machine

,

disposable plate making machine

Disposable Foam Plates Making Machine, EPS Lunch Box Production Line



PS foam food container production line included three systems: PS foam sheet extrusion line, PS foam food container forming and cutting integrated machine, PS foam material recycle machine.


1.PS Foam Sheet Extrusion Line adopts Gentian type double-stage series high foam technology. The raw material is polystyrene granules. In the extruding process, the vesicant -- butane gas is injected at high pressure. After extruding, foaming, cooling, shaping and hauling off, it is winding to finished PS foam sheet rolls. It is widely used in the packing
for food, fruit, and advertising industrial products and so on. This equipment adopts high-speed hydraulic filter changer which has a steady feature, can realize change the filter immediately without stopping the machine.



2.PS foam food container forming and cutting integrated machine was developed by combining the domestic and
foreign equipment and advantages. The main electrical components, such as vacuum pump, PLC, made in Japan and Germany, ensure the reliability of the equipment operation. After heating-vacuum forming-cutting-collecting process,
the finished PS foaming sheet can be made into the variety of packaging vessels such as fast food box, aquatic plate, supermarket tray, cake tray, KT board, instant noodle bowl, foam tray etc.



3.PS foam material recycle machine is special for polystyrene, who can make the excess PS foam sheet into
granules, so that can be used again. It adopts single screw, double stage plastification, increasing compress ratio.
The whole machine consists of the crusher, main machine, cooling tank, and granulator.





A. PS foam sheet extruder

PS Foam Sheet Extruder uses a tandem screw technology to produce fine-block cell-structured extruded polystyrene foam sheet with high strength and a pearl and even surface, in a continuous roll, from polystyrene injection an eco-friendly blowing gas and additives. It has a user friendly operating system with inverter controlled driving, digital temperature control and so on.

EPS Lunch Box Or Foam Plate Making Machine Forming Speed 15-20 Cycles / Min 0



Machine Specifications

Item Unit Parameter
Model   105/120
Applicable materials   GPPS granule(123P/525)
Thickness of sheet mm 1-3.5
Width of sheet mm 540~1080
Foaming rate   12-20
Weight of product kg/m³ 50~83
Output kg/h 150~200
Rated power(approximately) KW 180
Power supply   Three phase 380V/50Hz
External dimension mm 24000×4100×2800
Complete weight Ton About12

EPS Lunch Box Or Foam Plate Making Machine Forming Speed 15-20 Cycles / Min 1



B. Fully automatic forming and cutting machine



Fully automatic forming and cutting machine integrates forming, cutting and stacking (trimming) at the same time. It has the features of saving labor, improving efficient, lowing labor intensity and reducing production cost. It adopts PLC controller and touch screen to control the working program. Two workers are enough for whole production line.

The machine is plastic sheet forming equipment in one step with following process: transporting sheet, heating, forming, cutting, stacking and winding waste edge.



Item Unit Parameter
Model   HR-M1080
Power supply   Three phase 380V/50Hz
Production efficiency s/mold 2.8-5
Installed power (approximately) KW 250
Total weight (approximately) Ton 18
Mounting size m 14.2×5.8×3.14
Compressed air capacity m3/min 0.4~0.7
Compressed air pressure Mpa 0.7
Cooling water T/h 1

EPS Lunch Box Or Foam Plate Making Machine Forming Speed 15-20 Cycles / Min 2

C. PS recycle machine

1.Introduction:

This machine is special for polystyrene. It adopts single screw, double stage plasticification, increasing compress ratio. The whole machine consists of crusher, main machine, cooling tank and granulator. It can recycle many foamed products, such as PS, XPS, EPS etc.

2. Flow Chart:

Material —Put into—Crush—Inhalation storage silos—Melt—Extrude—Water tank cooling—Pulling—Pelletizing—Packaging

3.Main parameters

Model 105/300
Screw Diameter Φ105/300mm
Total power 45kw
Power supply three phase 380V/50Hz
Number of heating zones 4
Throughput 120kg/h
Applicable materials PS foam scrap

EPS Lunch Box Or Foam Plate Making Machine Forming Speed 15-20 Cycles / Min 3



Main Features

1) Suck and pull the food containers up. Even the containers don't be sucked out successfully, this won't affect next move.
2) There are one conveyor belt on each side, both can achieve automatically stacking, reduce labor intensity.
3) Heater box separate into three parts,hydraulic cutting speed is faster,and use mechanical arms to suck products,all above methods reduce the whole working time.
4) Extend mold length, making the forming mold area larger and improving the production efficiency.
5) Stacking system installed two sets of static eliminator to eliminate static electricity generated in the production process to avoid fires.

Packaging & Delivery

EPS Lunch Box Or Foam Plate Making Machine Forming Speed 15-20 Cycles / Min 4
