Product Details:
Payment & Shipping Terms:
|
| Voltage: | 220V/380V | Condition: | New |
|---|---|---|---|
| Warranty: | One Year | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Product Type: | Egg Tray Machine,Egg Box Machine | Capacity: | 6000-6500pcs/hr |
| Power(w): | 200KW | Raw Material: | Waste Paper,cartons And Mixed Waste Paper.,old Carton,Carton And Newspaper |
| Product Name: | Waste Carton Paper Pulp Recycled Moulding Egg Tray Making Machine | Color: | Customer Requests |
| Finished Products: | Fruit Tray,Egg Tray Egg Carton,coffee Tray,wine Tray | Type: | Automatic |
| Fuel: | Diesel,Natural Gas,Heavy Oil,LPG,Oil/gas/electric/diesel/as Your Request | ||
| High Light: | paper tray making machine,automatic egg tray making machine |
||
High Speed Automatic Paper Pulp Egg Tray / Carton Making Machine
Our molding machines and molding dies are fully designed by computer-assistant engineering and high technology. It has been proven high efficiency, low maintenance and energy saving during the ten year practice. The pulp molding system can use all kinds of waste paper to produce high quality molded fibre products. Such as, egg trays, egg boxes, apple trays, meat portion trays, vegetable portion trays, fruit portion trays, strawberry punnets, kidney trays, wine packs, can trays, seed pots, seed cubes, etc. it is a satisfyingly high return investment for the entrepreneurs or investors who wants a stable and consistent business.
The whole production line is fully automatic running, which can minimize labor costs.The specifications of the pulp molding production lines are divided due to different customer preferences, market demands, labor cost, energy cost, field availability and climate in different areas, considering this, our company developed many pulp molding production lines in different specifications to meet the customer’s requirements:
HRZ-2000M, HRZ-3000M, HRZ-4000M, HRZ-5000M, HRZ-6000M, HRZ-8000M.
The above mentioned production lines are suitable for the following products: Egg tray(30-packed, 20-packed etc.), egg box/carton(6-packed, 10-packed,12-packed, 6+6-packed,15-packed,18-packed and etc.), fruit tray(for apple, tomato, pear and etc.), cup carrier(4 packed and 2 packed), some medical-care products and fixed shape(the design doesn't change frequently) pulp molding products with large quantity.
HRZ-6000M rotary type automatic paper pulp molding production line system basic constitution
The HRZ-5000M rotary type automatic paper pulp molding production line constituted by five large-scale systems:
(1) Pulping system
(2) Forming machine
(3) Drying system
(4) Finished products automatic stacking, collection and manual packing system
(5) Electricity control system
Specification of HRZ-6000M egg tray machine
| Item | Information | Notes |
| Output Range | 6000pcs/h | 30 packed egg tray(60~80g) |
| Workshop recommendation | ≥600m2 |
Length≥40m;Width≥15m;Height≥6m; (It could be adjusted according to the user's existing workshop) |
| Type of Material | Waste paper |
Newspaper/Carton /Paper box/Books/ Corrugated paper/Kraft paper etc. |
| Material consumption | 360~480kg/h | 30 packed egg tray(60~80g) |
| Water consumption | 800-1050kg/h | 30 packed egg tray(60~80g) |
| Electricity consumption | 140-175kw/h | Full throttle operation |
|
Fuel consumption (approximately) |
LPG 55~70 kg/h |
30 packed egg tray(60~80g) Choose one from these types of fuel |
| Natural gas 85~100 m3/h | ||
| Diesel 65~80kg/h | ||
| Operator Required | 5~8 person/shift | 24hours, 3shift |
| Container requirement for Transport | 5 of 40 HQ container + 1 of 20’GP container | Whole production line |
Production flow chart
Advantage of egg tray machine
1. Raw material: Any kind of waste paper like old newspaper, magazines, books, A4 paper etc, and easy to get
2. Automation: Fully-automatic control
3. Quality standard: CE
4. 100% environmentally production process.
5. Engineers available to service machinery overseas.
Application
