Rotary Paper Pulp Molding Machine 200mm Height For Egg Tray / Wine Torr

Rotary Paper Pulp Molding Machine 200mm Height For Egg Tray / Wine Torr
Rotary Paper Pulp Molding Machine 200mm Height For Egg Tray / Wine Torr Rotary Paper Pulp Molding Machine 200mm Height For Egg Tray / Wine Torr Rotary Paper Pulp Molding Machine 200mm Height For Egg Tray / Wine Torr Rotary Paper Pulp Molding Machine 200mm Height For Egg Tray / Wine Torr

Large Image :  Rotary Paper Pulp Molding Machine 200mm Height For Egg Tray / Wine Torr

Product Details:

Place of Origin: CHINA
Brand Name: HONGRUN
Certification: ISO9001, CE, SGS, BV, TUV
Shaping machine type: Rotary type
Raw material: recycled paper
Fuel type: natural gas/diesel oil/coal
Warranty: ONE YEAR

Payment & Shipping Terms:

Minimum Order Quantity: 1SET
Price: negotiation
Packaging Details: Standard Export Packaging
Delivery Time: 80days
Payment Terms: T/T, L/C
Supply Ability: 100SETS PER YEAR
 Quality Guarantee: one year
Detailed Product Description
Warranty: One Year Voltage: 220V/380V,50HZ
Condition: New Product Type: Egg Tray Machine
Weight: 45T Processing Type: Pulp Molding Machine
Raw Material: Waste Paper Name: Egg Tray Making Machine
Production Capacity: 6000pcs Per Hour Finished Products: Egg Tray /wine Tray/yogurt Tray /fruit Tray/egg Box Ect.
Type: Full Automatic Rotary Type
High Light:

pulp molding machine

,

Paper moulding machine





Rotary Paper Pulp Molding Machine 200mm Height For Egg Tray / Wine Torr





Egg tray machine is a kind of machine which absorbs paper pulp-the raw material, on the surface of mould by vacuum to get various shape and ratio of wet and dry by regulating time. After such a working procedure as transferring moulds, releasing moulds to complete paper tray production. Our forming machines selecting high quality electronic devices and pneumatic components, high performance and long service life.



There are various types and output of egg tray making machines that can be supplied by our company, such as 1000pcs per hour, 2000pcs per hour,3000pcs per hour, 4000pcs per hour, 5000pcs per hour, 6000pcs per hour and so on. You only can tell me what capacity machine do you want,our professional engineer will design the most suitable machine for you!

HRZ-6000M rotary type automatic paper pulp molding production line system basic constitution

The HRZ-6000M rotary type automatic paper pulp molding production line constituted by five large-scale systems:

(1) Pulping system

(2) Forming machine

(3) Drying system

(4) Finished products automatic stacking, collection and manual packing system

(5) Electricity control system

Rotary Paper Pulp Molding Machine 200mm Height For Egg Tray / Wine Torr 0



Specifications&Advantages

Item Information Notes
Output Range 6000pcs/h 30 packed egg tray(60~80g)
Workshop recommendation ≥600m2

Length≥40m;Width≥15m;Height≥6m;

(It could be adjusted according to the user's existing workshop)

Type of Material Waste paper

Newspaper/Carton /Paper box/Books/

Corrugated paper/Kraft paper etc.

Material consumption 360~480kg/h 30 packed egg tray(60~80g)
Water consumption 800-1050kg/h 30 packed egg tray(60~80g)
Electricity consumption 140-175kw/h Full throttle operation

Fuel consumption

(approximately)

LPG 55~70 kg/h

30 packed egg tray(60~80g)

Choose one from these types of fuel

Natural gas 85~100 m3/h
Diesel 65~80kg/h
Operator Required 5~8 person/shift 24hours, 3shift
Container requirement for Transport 5 of 40 HQ container + 1 of 20’GP container Whole production line

1.High production

2.Easy to install and operate

3.Rugged construction

4.Heat resistance

5.Competitive price

6.Green:No waste paper emission

7.Stable final product quality(Good&strong look, same weight and size)

8.Space saving & low investment

9.Best pre-sale, in-sale and after-sale service.



Production flow chart

Rotary Paper Pulp Molding Machine 200mm Height For Egg Tray / Wine Torr 1

Application

The tray of eggs, paper pulp egg holder, quail egg boxes, eggs in a box, egg crate, egg tray, egg container, egg cartons for
sale, chicken egg holder etc.

Egg tray 20, 30, 40 packed egg tray… quail egg tray
Egg carton 4, 6, 9, 10, 12, 15, 18, 24 packed egg carton…
Agricultural products Fruit tray, seeding cup
Cup salver 2, 4 cup salver
Disposable Medical Care Products Bedpan, sick pad, female urinal…
Packages Shoe tree, industrial package…



Rotary Paper Pulp Molding Machine 200mm Height For Egg Tray / Wine Torr 2
