Small Scale Manual Pulp Tray Machine / Egg Carton Molding Machine

Small Scale Manual Pulp Tray Machine / Egg Carton Molding Machine
Small Scale Manual Pulp Tray Machine / Egg Carton Molding Machine Small Scale Manual Pulp Tray Machine / Egg Carton Molding Machine Small Scale Manual Pulp Tray Machine / Egg Carton Molding Machine

Large Image :  Small Scale Manual Pulp Tray Machine / Egg Carton Molding Machine

Product Details:

Place of Origin: CHINA
Brand Name: HONGRUN
Certification: ISO9001, CE, SGS, BV, TUV
Model Number: HRZ-1000

Payment & Shipping Terms:

Minimum Order Quantity: 1SET
Packaging Details: Standard Export Packaging
Delivery Time: 50days
Payment Terms: T/T, L/C
Supply Ability: 100SETS PER YEAR
Detailed Product Description
Warranty: 12 Months Voltage: 220V50HZ/380V50HZ
Power(w): 28kw Condition: New
Weight: 2.2T Product Type: Egg Tray Machine
Dimension(l*w*h): 3.3m*2.2m*2.5m Processing Type: Pulp Molding Machine
After-sales Service Provided: Engineers Available To Service Machinery Overseas Production Capacity: 1000pcs/hour.
Raw Material: Waste Paper,waste Bin,old Carton Color: Customized Color
Finished Products: Egg Tray Egg Carton,fruit Tray,coffee Tray,wine Tray Application: Packing Industry,Egg Tray,Egg Tray Moulding/ Waste Paper Making
Total Power: 33 Kw
High Light:

pulp egg tray making machine

,

pulp molding equipment

Small Scale Manual Pulp Egg Carton Tray Molding Machine Pulp Tray Machine



Product Description:
Pulp Moulding Machine is known as egg tray line for using massively in produce egg tray.
Pulp Moulding Machine, which uses waste paper, cardboard, leftover material of paper mill, by hydraulic pulper, mix making a certain dense pulp, and pulp is absorbed by vacuum of special metal moulding to become wet products, through drying , and shaping to become finished products.
Pulp Moulding Line processing makes use of recycled water and does not lead to water or air pollution. Finished packaging products can be recycled after being used in storage, transport, and sales. After shredding, they are easy to be decomposed as paper, even if discarded into the natural environment.
Automatic pulp molding production lines can be mass production of various food container, egg tray, lunch boxes and so on.
The major equipment of the machine are three parts include: Pulp Making System, Molding System, Drying system and packing system.

Technical data



Item Information Notes
Output 1000pcs/h

30 packed egg tray

(60~90g)

Workshop recommendation ≥200m2

Length≥20m;width≥10m;height≥6m;

(It could be adjusted according to the user's existing workshop)

Type of Material Waste paper

Newspaper/Carton/Paper box/Books/

Corrugated paper etc.

Electricity consumption 23-30kW·h/hr Full throttle operation
Material consumption 65~80kg/hr

30 packed egg tray

(60~90g)

Water consumption 150-180kg/hr

30 packed egg tray

(60~90g)

Operator Required 2-4 people/shift 24hours, 3shift
Container requirement for Transport 1 of 20’GP container Whole production line



The production line is mainly combined by THREE PARTS:
1. Pulping system
(meaning: Use waste paper and water as raw material and pulp up) ;

2. Forming system
(meaning: The pulped material being delivered to Egg tray moulds, and forming to the Egg tray plate shape) ;

3. Drying system
(Meaning : The formed Egg tray plate being delivered to Dryer, and come up to Completed Strong Egg tray plate) .

The drying system is with one boiler. The drying system can use electricity, or diesel, or coal, or natural gas as energy. Customers must first confirm which kind of energy they will use before our production.

Small Scale Manual Pulp Tray Machine / Egg Carton Molding Machine 0



Production flow

Small Scale Manual Pulp Tray Machine / Egg Carton Molding Machine 1



After-sales Service

  1. Our company view adhering to the "excellent quality, customer satisfaction" service concept, to provide you with excellent products and perfect service.
  2. Our company keep the contract and reputation. Quality first, products guarantee a year, as it is quality problem, free replacement.
  3. For every purchase of our company's products, the company can send technicians to guide the installation and debugging, and can undertake the design of process and equipment installation.
  4. Our company ensure that supply of parts discount all the year round.
