Eco-friendly Recycling Egg Carton Machine Pulp Molding Egg Tray Making Machine
Egg Tray Machine (pulp moulding machine) consume used waste paper as raw material and produce different kinds of paper tray according to your requirement,such as egg tray/dishes ,egg carton/box,fruit tray,industrial package tray,seeding tray ,win tray ,shoe support and small products packages ,etc. The different final products are decided by your market choice.
1. Main equipment of egg carton machine
1. Pulp molding system: Hydraulic pulper, High-frequency vibration sieve frame, Pulp pump, Strengthening of self-priming pump, Agitator, Control cabinet of pulping system
2. Forming system: Rotary forming machine, Molds, Vacuum pump, Screw Air Compressor, Vacuum buffer tank, Air compressor storage tank, White Water pump, High-pressure water pump, Refiner machine, Power cabinet of forming system
3. Drying system: Conveyor, Blower, Induced fan, Burner, Bellows, etc
4. Packing system: Packing machine
2. Feature of Professional Paper Egg Tray Making Machine Price/egg Tray Machine Production Line
| 1 |
High automation, low labor cost |
| 2 |
Low production cost |
| 3 |
Energy-saving(by 30%-50% compared with other manufacturers) |
| 4 |
Water-saving(complete water treatment system equipped) |
| 5 |
Efficient Multilayer dryer, saving space(by 33% compared with traditional dryer) |
| 6 |
Stable final product quality(same weight, same dimension, strong and good look) |
3. Technical data
| Item |
Information |
Notes |
| Output Range |
2000pcs/h |
30 packed egg tray(60~80g) |
| Workshop recommendation |
≥480m2 |
Length≥32m;Width≥15m;Height≥6m;
(It could be adjusted according to the user's existing workshop)
|
| Type of Material |
Waste paper |
Newspaper/Carton /Paper box/Books/
Corrugated paper etc.
|
| Material consumption |
120~160kg/h |
30 packed egg tray(60~80g) |
| Water consumption |
265-350kg/h |
30 packed egg tray(60~80g) |
| Electricity consumption |
70-90kw |
Full throttle operation |
|
Fuel consumption
(approximately)
|
LPG 30~40 kg/h |
Choose one from the three types of fuel |
| Natural gas 35~50 m3/h |
| Diesel 30~40 kg/h |
| Operator Required |
4~6 people/shift |
24hours, 3shift |
| Container requirement for Transport |
2 of 40’HQ container +
1 of 20’GP container
|
Whole production line |
The reason why you choose us:
1. Forming system: reasonable design, automatic oil feeding, and automatic moving spray devices are configured.
2. Heating system: multi-layer conveyor design is With Italian technology synchronization, adopt direct heating way, to ensure more high-efficiency heat absorbing and floor space-saving. Can be more energy-saving at least 20% than the others
3. we are engaged in producing and research in this field more than ten years, we have rich experience to provide you line with intelligent design and competitive price, we have exported our paper molding line to more than ten countries and regions as Algeria, America, Peru, Libya, Ukraine, Sudan, Ghana, Saudi Arabia, Chile, etc.
4. we never give up innovation and creation to help our customers maximize to make profits.
